GC syringes

Description: 10 µL Syringe with metal plunger, 23-26G Fixed needle, 42 mm needle length, Cone tip style

Description: 5 µl Syringe for OCI, Fixed needle, 42 mm needle length, Cone tip style. 23G reduced to 26G

Description: Fixed needle syringe with super flexible titanium alloy plunger. They are resistant to bending and sliding friction for extended lifetime, even with water soluble samples. Plunger and barrel are machined for an exact fit, so they are not interchangeable with another syringe if either part is damaged. Syringe Volume Min. Sample  Volume Needle Length (mm) Needle Gauge Needle OD (mm) Needle ID (mm) Needle tip P/N 5 μL 0.1 μL 43 23 0.64 0.15 Cone 227-35401-01 10 μL 0.2 μL 43 23 0.64 0.15 Cone 227-35400-01

Description: Fixed needle syringe with super flexible titanium alloy plunger. They are resistant to bending and sliding friction for extended lifetime, even with water soluble samples. Plunger and barrel are machined for an exact fit, so they are not interchangeable with another syringe if either part is damaged. Syringe Volume Min. Sample  Volume Needle Length (mm) Needle Gauge Needle OD (mm) Needle ID (mm) Needle tip P/N 5 μL 0.1 μL 43 23 0.64 0.15 Cone 227-35401-01 10 μL 0.2 μL 43 23 0.64 0.15 Cone 227-35400-01

Description: Syringe for AOC-6000, headspace (HS) injection   Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle Tip Part Number 1 μL - 57 23 0.63 Cone 225-19744-01 5 μL - 57 26 0.47 Cone 225-19744-02 5 μL - 57 23 0.63 Cone 227-37166-01 5 μL - 85 23 0.63 Cone 227-37160-01 10 μL - 57 26 0.47 Cone 225-19744-03 10 μL √ 57 26 0.47 Cone 225-19744-04 10 μL - 57 23 0.63 Cone 227-37167-01 10 μL - 85 23 0.63 Cone 227-37161-01 25 μL √ 57 26 0.47 Cone 225-19744-05 50 μL √ 57 26 0.47 Cone 225-19744-06 100 μL √ 57 26 0.47 Cone 225-19744-07 250 μL √ 57 26 0.47 Cone 225-19744-08 500 μL √ 57 26 0.47 Cone 225-19744-09 1 mL √ 57 23 0.63 Side Hole Dome 225-19744-10 2.5 mL √ 65 23 0.63 Side Hole Dome 225-19744-11

Description: Syringe for AOC-6000, headspace (HS) injection   Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle Tip Part Number 1 μL - 57 23 0.63 Cone 225-19744-01 5 μL - 57 26 0.47 Cone 225-19744-02 5 μL - 57 23 0.63 Cone 227-37166-01 5 μL - 85 23 0.63 Cone 227-37160-01 10 μL - 57 26 0.47 Cone 225-19744-03 10 μL √ 57 26 0.47 Cone 225-19744-04 10 μL - 57 23 0.63 Cone 227-37167-01 10 μL - 85 23 0.63 Cone 227-37161-01 25 μL √ 57 26 0.47 Cone 225-19744-05 50 μL √ 57 26 0.47 Cone 225-19744-06 100 μL √ 57 26 0.47 Cone 225-19744-07 250 μL √ 57 26 0.47 Cone 225-19744-08 500 μL √ 57 26 0.47 Cone 225-19744-09 1 mL √ 57 23 0.63 Side Hole Dome 225-19744-10 2.5 mL √ 65 23 0.63 Side Hole Dome 225-19744-11

Description: Syringe for AOC-6000, headspace (HS) injection   Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle Tip Part Number 1 μL - 57 23 0.63 Cone 225-19744-01 5 μL - 57 26 0.47 Cone 225-19744-02 5 μL - 57 23 0.63 Cone 227-37166-01 5 μL - 85 23 0.63 Cone 227-37160-01 10 μL - 57 26 0.47 Cone 225-19744-03 10 μL √ 57 26 0.47 Cone 225-19744-04 10 μL - 57 23 0.63 Cone 227-37167-01 10 μL - 85 23 0.63 Cone 227-37161-01 25 μL √ 57 26 0.47 Cone 225-19744-05 50 μL √ 57 26 0.47 Cone 225-19744-06 100 μL √ 57 26 0.47 Cone 225-19744-07 250 μL √ 57 26 0.47 Cone 225-19744-08 500 μL √ 57 26 0.47 Cone 225-19744-09 1 mL √ 57 23 0.63 Side Hole Dome 225-19744-10 2.5 mL √ 65 23 0.63 Side Hole Dome 225-19744-11

Description: Syringe for AOC-6000, headspace (HS) injection   Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle Tip Part Number 1 μL - 57 23 0.63 Cone 225-19744-01 5 μL - 57 26 0.47 Cone 225-19744-02 5 μL - 57 23 0.63 Cone 227-37166-01 5 μL - 85 23 0.63 Cone 227-37160-01 10 μL - 57 26 0.47 Cone 225-19744-03 10 μL √ 57 26 0.47 Cone 225-19744-04 10 μL - 57 23 0.63 Cone 227-37167-01 10 μL - 85 23 0.63 Cone 227-37161-01 25 μL √ 57 26 0.47 Cone 225-19744-05 50 μL √ 57 26 0.47 Cone 225-19744-06 100 μL √ 57 26 0.47 Cone 225-19744-07 250 μL √ 57 26 0.47 Cone 225-19744-08 500 μL √ 57 26 0.47 Cone 225-19744-09 1 mL √ 57 23 0.63 Side Hole Dome 225-19744-10 2.5 mL √ 65 23 0.63 Side Hole Dome 225-19744-11

Description: SYRINGE FOR TOC-V / TOC-L, 5 ML. Replacement for 638-59213

Description: Removable Needle Style Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy exchange. Needle tip: Syringe termination:   Syringe Volume Needle O.D. (mm) Needle Length (mm) Syringe Part Number Replacement Needle Part number 0.25 mL 0.56 30 670-12504-28 670-12504-85 0.5 mL 0.56 30 670-12504-29 670-12504-85 1 mL 0.56 30 670-12504-30 670-12504-85 2.5 mL 0.56 30 670-12504-31 670-12504-85 5 mL 0.56 30 670-12504-32 670-12504-85 10 mL 0.56 30 670-12504-33 670-12504-85

Description: Removable Needle Style Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy exchange. Needle tip: Syringe termination:   Syringe Volume Needle O.D. (mm) Needle Length (mm) Syringe Part Number Replacement Needle Part number 0.25 mL 0.56 30 670-12504-28 670-12504-85 0.5 mL 0.56 30 670-12504-29 670-12504-85 1 mL 0.56 30 670-12504-30 670-12504-85 2.5 mL 0.56 30 670-12504-31 670-12504-85 5 mL 0.56 30 670-12504-32 670-12504-85 10 mL 0.56 30 670-12504-33 670-12504-85

Description: Removable Needle Style Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy exchange. Needle tip: Syringe termination:   Syringe Volume Needle O.D. (mm) Needle Length (mm) Syringe Part Number Replacement Needle Part number 0.25 mL 0.56 30 670-12504-28 670-12504-85 0.5 mL 0.56 30 670-12504-29 670-12504-85 1 mL 0.56 30 670-12504-30 670-12504-85 2.5 mL 0.56 30 670-12504-31 670-12504-85 5 mL 0.56 30 670-12504-32 670-12504-85 10 mL 0.56 30 670-12504-33 670-12504-85

Description: Removable Needle Style Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy exchange. Needle tip: Syringe termination:   Syringe Volume Needle O.D. (mm) Needle Length (mm) Syringe Part Number Replacement Needle Part number 0.25 mL 0.56 30 670-12504-28 670-12504-85 0.5 mL 0.56 30 670-12504-29 670-12504-85 1 mL 0.56 30 670-12504-30 670-12504-85 2.5 mL 0.56 30 670-12504-31 670-12504-85 5 mL 0.56 30 670-12504-32 670-12504-85 10 mL 0.56 30 670-12504-33 670-12504-85

Description: Removable Needle Style Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy exchange. Needle tip: Syringe termination:   Syringe Volume Needle O.D. (mm) Needle Length (mm) Syringe Part Number Replacement Needle Part number 0.25 mL 0.56 30 670-12504-28 670-12504-85 0.5 mL 0.56 30 670-12504-29 670-12504-85 1 mL 0.56 30 670-12504-30 670-12504-85 2.5 mL 0.56 30 670-12504-31 670-12504-85 5 mL 0.56 30 670-12504-32 670-12504-85 10 mL 0.56 30 670-12504-33 670-12504-85

Description: Removable Needle Style Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy exchange. Needle tip: Syringe termination:   Syringe Volume Needle O.D. (mm) Needle Length (mm) Syringe Part Number Replacement Needle Part number 0.25 mL 0.56 30 670-12504-28 670-12504-85 0.5 mL 0.56 30 670-12504-29 670-12504-85 1 mL 0.56 30 670-12504-30 670-12504-85 2.5 mL 0.56 30 670-12504-31 670-12504-85 5 mL 0.56 30 670-12504-32 670-12504-85 10 mL 0.56 30 670-12504-33 670-12504-85

Description: Removable Needle Style Gastight syringes with a capacity of milliliter quantity level. The needle is 30mm long and is of a screw-in type, which ensures an easy exchange. Needle tip: Syringe termination:   Syringe Volume Needle O.D. (mm) Needle Length (mm) Syringe Part Number Replacement Needle Part number 0.25 mL 0.56 30 670-12504-28 670-12504-85 0.5 mL 0.56 30 670-12504-29 670-12504-85 1 mL 0.56 30 670-12504-30 670-12504-85 2.5 mL 0.56 30 670-12504-31 670-12504-85 5 mL 0.56 30 670-12504-32 670-12504-85 10 mL 0.56 30 670-12504-33 670-12504-85

Description: Manual Fixed Needle Style Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle ID (mm) Needle Tip Syringe Part Number Replacement Plunger Part Number 5 μL - 50 26 0.47 0.11 Bevel 221-75170 - 10 μL - 50 26 0.47 0.11 Bevel 670-12552-01 - 10 μL √ 80 26 0.47 0.11 Bevel 221-75170-01 221-75170-02 25 μL - 80 25 0.5 0.2 Bevel 670-12510-31 - 25 μL √ 50 25 0.5 0.2 Bevel 221-75171 221-75171-01 50 μL - 50 25 0.5 0.2 Bevel 670-12510-36 - 50 μL √ 50 25 0.5 0.2 Bevel 221-75172 221-75172-03 100 μL - 50 25 0.5 0.2 Bevel 670-12510-18 - 100 μL √ 50 25 0.5 0.2 Bevel 221-75172-01 221-75172-04 250 μL - 50 25 0.5 0.2 Bevel 670-12510-19 - 250 μL √ 50 25 0.5 0.2 Bevel 221-75172-02 221-75172-05 500 μL - 50 25 0.5 0.2 Bevel 670-12510-20 -

Description: Manual Fixed Needle Style Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle ID (mm) Needle Tip Syringe Part Number Replacement Plunger Part Number 5 μL - 50 26 0.47 0.11 Bevel 221-75170 - 10 μL - 50 26 0.47 0.11 Bevel 670-12552-01 - 10 μL √ 80 26 0.47 0.11 Bevel 221-75170-01 221-75170-02 25 μL - 80 25 0.5 0.2 Bevel 670-12510-31 - 25 μL √ 50 25 0.5 0.2 Bevel 221-75171 221-75171-01 50 μL - 50 25 0.5 0.2 Bevel 670-12510-36 - 50 μL √ 50 25 0.5 0.2 Bevel 221-75172 221-75172-03 100 μL - 50 25 0.5 0.2 Bevel 670-12510-18 - 100 μL √ 50 25 0.5 0.2 Bevel 221-75172-01 221-75172-04 250 μL - 50 25 0.5 0.2 Bevel 670-12510-19 - 250 μL √ 50 25 0.5 0.2 Bevel 221-75172-02 221-75172-05 500 μL - 50 25 0.5 0.2 Bevel 670-12510-20 -

Description: Manual Fixed Needle Style Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle ID (mm) Needle Tip Syringe Part Number Replacement Plunger Part Number 5 μL - 50 26 0.47 0.11 Bevel 221-75170 - 10 μL - 50 26 0.47 0.11 Bevel 670-12552-01 - 10 μL √ 80 26 0.47 0.11 Bevel 221-75170-01 221-75170-02 25 μL - 80 25 0.5 0.2 Bevel 670-12510-31 - 25 μL √ 50 25 0.5 0.2 Bevel 221-75171 221-75171-01 50 μL - 50 25 0.5 0.2 Bevel 670-12510-36 - 50 μL √ 50 25 0.5 0.2 Bevel 221-75172 221-75172-03 100 μL - 50 25 0.5 0.2 Bevel 670-12510-18 - 100 μL √ 50 25 0.5 0.2 Bevel 221-75172-01 221-75172-04 250 μL - 50 25 0.5 0.2 Bevel 670-12510-19 - 250 μL √ 50 25 0.5 0.2 Bevel 221-75172-02 221-75172-05 500 μL - 50 25 0.5 0.2 Bevel 670-12510-20 -

Description: Manual Fixed Needle Style Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle ID (mm) Needle Tip Syringe Part Number Replacement Plunger Part Number 5 μL - 50 26 0.47 0.11 Bevel 221-75170 - 10 μL - 50 26 0.47 0.11 Bevel 670-12552-01 - 10 μL √ 80 26 0.47 0.11 Bevel 221-75170-01 221-75170-02 25 μL - 80 25 0.5 0.2 Bevel 670-12510-31 - 25 μL √ 50 25 0.5 0.2 Bevel 221-75171 221-75171-01 50 μL - 50 25 0.5 0.2 Bevel 670-12510-36 - 50 μL √ 50 25 0.5 0.2 Bevel 221-75172 221-75172-03 100 μL - 50 25 0.5 0.2 Bevel 670-12510-18 - 100 μL √ 50 25 0.5 0.2 Bevel 221-75172-01 221-75172-04 250 μL - 50 25 0.5 0.2 Bevel 670-12510-19 - 250 μL √ 50 25 0.5 0.2 Bevel 221-75172-02 221-75172-05 500 μL - 50 25 0.5 0.2 Bevel 670-12510-20 -

Description: Manual Fixed Needle Style Syringe Volume PTFE Tipped Plunger Needle Length (mm) Needle Gauge Needle OD (mm) Needle ID (mm) Needle Tip Syringe Part Number Replacement Plunger Part Number 5 μL - 50 26 0.47 0.11 Bevel 221-75170 - 10 μL - 50 26 0.47 0.11 Bevel 670-12552-01 - 10 μL √ 80 26 0.47 0.11 Bevel 221-75170-01 221-75170-02 25 μL - 80 25 0.5 0.2 Bevel 670-12510-31 - 25 μL √ 50 25 0.5 0.2 Bevel 221-75171 221-75171-01 50 μL - 50 25 0.5 0.2 Bevel 670-12510-36 - 50 μL √ 50 25 0.5 0.2 Bevel 221-75172 221-75172-03 100 μL - 50 25 0.5 0.2 Bevel 670-12510-18 - 100 μL √ 50 25 0.5 0.2 Bevel 221-75172-01 221-75172-04 250 μL - 50 25 0.5 0.2 Bevel 670-12510-19 - 250 μL √ 50 25 0.5 0.2 Bevel 221-75172-02 221-75172-05 500 μL - 50 25 0.5 0.2 Bevel 670-12510-20 -

Description: Plunger-in-needle style. The plunger goes into the needle tip, sample is completely dispensed and dead volume eliminated. This is ideal for highly precise analysis of microvolume samples.

Description: Plunger-in-needle style. The plunger goes into the needle tip, sample is completely dispensed and dead volume eliminated. This is ideal for highly precise analysis of microvolume samples.
